Interactive Touch Screen Monitor 55 65 75 86 98 110 Inch Android
WIN Multi Touch Educational Smart Board For Kids Teach
Advantages points for iboard android touch all in one screen
monitors:
1.Use Ultra HD 4K resolution screen, bring a vivid imaging
experience and better visual experience
2.Support dual system, easy to switch between android and Windows
OS
3.20 point touch for both andorid and windows, support multiple
person writing simultaneously.
4.Support Gesture Eraser , and use your palm to erase the writing
contents easily.
5.Suppoting wireless share upto 9 screens for
pad/phone/laptop,etc.at one time
6.with IBOARD whiteboard software for
annotation/share/record/meeting room,etc.
7. Optional to built in camera or out-connected for 8mp/13mp/48mp
camera
8. Optional to built in microphone or out-connected for 4/6/8 array
microphone
9. Available slze: 55/65/75/86/98/110 inch
10.Certificates:CE/ROHS/FCC,etc.
Specifications sheet:
| Item | Interactive Touch Screen Monitor 55 65 75 86 98 110 Inch Android
WIN Multi Touch Educational Smart Board For Kids Teach |
| Model | TE-YL-65 |
| Display size(mm) | 1428.5*803.5 |
| Resolution | 3840*2160 |
| Brightness | 350cd/m2 |
| Contrast | 4000:1 |
| Aspect ratio | 16:9 |
| Response time | 8ms |
| Screen mode | 16:9/4:3/dot to dot/full screen |
| Glass | Anti Glare 3mm tempered glass |
| Android version | 11 or 13 optional 4 x ARM Cortex-A55@1.9GHz,with Dual 5.0GHz WiFi Moudle , one for
WIFI, one for hotspot,bluetooth 5.0 |
| RAM and storage | 4+32G |
| Wireless share | supporting for 9 screens at one time for
phone/pad/laptop/computer/IFPD,etc. |
| Camera | Optional to be built-in for 8mp/13mp/48mp camera or out-connected |
| Microphone | Optional to be built-in for 4/6/8 array microphone or out-connected |
| Input ports | Rear: 2*HDMI2.0, 1*VGA&AUDIO IN, 1*YPBPR, 2*USB 3.0, 1*USB2.0,
1*TOUCH-USB, 1*TF card, 1*RS232, 1*RJ45 IN, 1*AV IN, 1*MIC IN,
1*DP, 1*Type C(only for USB), 1*OPS SLOT
Front: 1*HDMI2.0, 1*TOUCH USB, 3*USB3.0, TYPE-C (Support Touch,
Data, Video and Audio transfer, charging(standard 15W, optional
65W) |
| Output ports | 1*HDMI-out, 1*COAXIAL, 1*Earphone, 1*RJ45 OUT, 1*AV OUT |
| Front keys | 8KEY(POWER,SOURCE,MENU,VOL-,VOL+,HOME,ENTER, ES) |
| Light sensor | Integrated light sensor for brightness detector that automatically
adjusts the brightness of the panel according to ambient light. |
| NFC function | Optional |
| Speaker | 2*15W |
| Voltage | AC(100～240)V-50/60HZ |
| Accessories | Touch pen*2,HDMI cable*1,Touch USB cable*1,Remote
controller*1,Power supply cable*1,wall mounted bracket*1 set |
| Packing size | 1646*225*1050mm |
| N.W.(KGS) | 38 |
| G.W.(KGS) | 52 |
Whiteboard software functions:
Packing:1pc/carton,optional to be with wooden crate
